EFI Advanced Part 12 takes a look at closed loop PID style control in our EFI systems. We explore each term in the PID control individually and put them together to get the big picture in closed loop control from our ECU. Finally, we look at a real world example to see how PID control is implemented to present a clear picture of the control routine and purpose.
